Door Thickness - The Innova system includes a 54mm door made to size, lipped, kraft papered and primed.
Wall Thickness - Please measure the total thickness of the studs and the drywall on the finished wall.
Hinge Type - The Innova system works with a special pivot which allows the door to sit flush within the frame but still be opened, this is supplied as standard. If you want your door to self close we offer a floorspring option. This maybe required when using a fire door, please check with your local building control for confirmation.
Strike Plate - Please select which strike plate you require. This is dependent on the type of lock your using e.g. Latch, Sashlock, or Deadlock (examples shown in images below). The price includes for the strike plate and all the preparation to the frame. (not the lock / latch)
Please note these prices are for a specialist bespoke strike plates designed to work with the Innova frame system.
Handing - Please select the type of handing you require. Left or Right. For further information please see the handing diagram below.
If you require any further information please call 0113 245 9559 or email info@invisibledoors.co.uk
Arriva is a flush door frame system that is used to create and enhance minimalist interiors and for concealing doors, riser doors and service cupboards. The concealed frame system is used on the outward opening Arriva system and frameless cupboard system.
